Equipment

• Grundfos® CR 3-15 pump
• 300 psi membrane housings
• Electrical panel with Ecosoft controller
• Danfoss solenoid valves
• Piping, instrumentation
• Steel frame
• Wooden crate

Options

• Filmtec™ ХLE-4040 / LCLE-4040 or Ecosoft ELP-4040 membranes

Connections:

• influent water — 3/4″
• permeate — 1″
• concentrate — ½”

Specifications

• Permeate capacity* — 1500 L/h
• Permeate recovery** — 75%
• Maximum TDS — 3000 mg/L
• Influent flow demand — 2000…2500 L/h (service)
• Operation pressure — 8…12 bar
• Maximum pressure — 14 bar
• Electrical requirements — 230 V, 50 Hz (1 ph)
• Electrical power — 1.4 kW
• Prefilter rating — 5 μm

* depends on feed water TDS, temperature, and permeate recovery

**  for low scaling/fouling water

Feed water requirements

• Influent water temperature — +5…+40 °С
• Residual chlorine, max — 0.1 mg/L
• Hardness — up to 3 meq/L (150 mg/L CaCO₃)
• Iron — up to 0.1 mg/L
• Manganese — up to 0.05 mg/L
• Silicate — up to 20 mg/L
• Chemical oxygen demand, max  — 4.0 mg О₂/L
• Hydrogen sulfide – none

The limitations may be exceeded if using antiscalant, oxygen scavenger, or other RO chemical pretreatment.

OC5000 controller

The OC5000 controller is designed for automatic or manual control of reverse osmosis unit and provides:

• automatic switching on and off of the equipment upon signal;
• emergency shutdown of the equipment by signals from dry-running sensors, overpressure in the module;
• shutdown of equipment on the external STOP signal.
